KAI-500MS Fusing Machine

Get a Price/Quote

MOQ : 10 Units

KAI-500MS Fusing Machine Specification

Cooling System
Built-in Fan Cooling

Features
Auto Belt Tracking, Digital Temp & Speed Control, Energy Efficient

Frequency
50/60 Hz

Lubricating System
Automatic

Machine Type
Fusing Press

Production Capacity
800-1000 Pcs/hr

Model No
KAI-500MS

Drive
AC Motor Drive

Accuracy
±1℃ Temperature Control

Control System
Digital Controller

Operating Temperature
Up to 200℃

Power Rating
4.5 kW

Motor Power
0.55 kW

Frame Type
Heavy Duty

Noise Level
≤65 dB

Voltage
220V / 380V

Product Type
Fusing Machine

Technology
Latest Fusing Technology

Power Source
Electric

Operating Type
Automatic

Power
4.5 kW

Pressure
0.4-0.6 MPa

Surface Treatment
Powder Coated

Dimension (L*W*H)
1550 x 950 x 1200 mm

Weight (kg)
400 kg

Color
Blue & White

Usage & Applications
Garment & Textile Industry

Application Material
Interlining, Fusible Fabrics, Woven & Non-Woven Materials

Time Range
0-99 Seconds

Adjustment Method
Digital Adjustment for Temperature and Pressure

Roller Surface
High Temperature Resistant

Heating Length
500 mm

Display Type
LED/LCD Display

Safety
Emergency Stop Switch

Energy Consumption
Optimized for Low Power Use

Conveyor Belt Material
PTFE Coated

Compatible Materials
Shirt Collar, Cuff, Waistband, Placket, etc.

Max Fusing Width
450 mm

Heat Source
Infrared Heating Element

Installation
Floor Standing

KAI-500MS Fusing Machine Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About KAI-500MS Fusing Machine

Procure the KAI-500MS Fusing Machine and seize first-rate deals on this prodigious solution for the garment and textile industry. With optimum performance powered by an advanced infrared heating element and a high-temperature-resistant roller surface, this machine delivers unmatched accuracy (1C) and energy efficiency. The PTFE-coated conveyor ensures smooth operation, while digital controllers grant precise temperature and pressure adjustment. Safety is paramount with an emergency stop switch. Avail appreciation-worthy discounts from trustworthy suppliers, traders, and wholesalers in India and elevate your production capacity to an impressive 800-1000 pieces per hour.

KAI-500MS Fusing Machine: Special Features & Application Surface

Experience optimum efficiency with the KAI-500MS Fusing Machine, designed for automatic operation and suited for both woven and non-woven materials. The machine boasts digital adjustment of temperature and pressure, a robust roller surface resistant to high temperatures, and a PTFE-coated conveyor belt for seamless fabric movement. Its surface adapts perfectly to shirt collars, cuffs, waistbands, and plackets, making it an indispensable asset in the garment and textile sector.

Export Markets, Domestic Reach & Sample Policies for KAI-500MS

We deliver the KAI-500MS Fusing Machine to major export markets worldwide, with a focus on reliable logistics and timely shipment. Our domestic network extends across major regions in India, ensuring prompt access and service. Prospective clients can request samples as per company policy, with careful consideration given to logistics and shipping arrangements for trial orders, thereby enhancing customer confidence through transparent trade practices and streamlined export market procedures.

FAQ's of KAI-500MS Fusing Machine:

Q: How does the KAI-500MS Fusing Machine optimize energy consumption during operation?

A: The KAI-500MS is engineered for energy efficiency, using a modern infrared heating element and an automatic lubricating system. Its digital controller precisely manages temperature and pressure, reducing unnecessary power use and ensuring optimal performance with every cycle.

Q: What are the main usage applications of the KAI-500MS Fusing Machine?

A: This fusing machine is ideal for applying interlining, fusible fabrics, and both woven and non-woven materials. It's especially suited for garment components such as shirt collars, cuffs, waistbands, and plackets within the textile and apparel industry.

Q: Where is the KAI-500MS Fusing Machine primarily installed and who can benefit from it?

A: The KAI-500MS is floor standing and typically installed in garment manufacturing units, textile workshops, and large-scale apparel factories. Suppliers, traders, wholesalers, and production managers seeking high efficiency and reliable fusing will benefit most from this product.

Q: What advanced safety and control features are included in the KAI-500MS?

A: The machine features an emergency stop switch, auto belt tracking, digital controls for temperature and speed, and a built-in fan cooling system. This ensures user safety and consistent, high-quality results with each operation.

Q: How does a customer request a sample, and what is the logistics process for shipment?

A: Interested buyers can request a sample as outlined in our company's sample policy. Once approved, the sample is carefully packed and shipped through reliable logistics partners, supporting both domestic and international export markets for prompt delivery.
